PTZOptics Move 4K SDI/HDMI/USB/IP PTZ Camera with 20x Optical Zoom (White)

Add a high-resolution streaming and tracking camera to your classroom, house of worship, or conference room for remote meetings with software such as Skype, Microsoft Teams, or Zoom with the white Move 4K SDI/HDMI/USB/IP PTZ Camera with 20x Optical Zoom from PTZOptics. The Move 4K camera captures resolutions up to UHD 4K60 via IP and HDMI, 1080p60 over 3G-SDI, and it features auto-tracking for presentations where your subject moves around the room, great for education, how-to, and corporate environments without the need for an operator. Its wide dynamic range, 3D noise reduction, and low-bandwidth, high-quality NDI|HX 3 capabilities provide a sharp, consistent image, even in low light.
The camera's features include a 1/1.8" 4K CMOS 8.42MP sensor for crisp imagery. The built-in zoom lens has an optical zoom range of 20x, and you can zoom in further with up to 16x digital zoom. With 255 programmable preset positions via serial, you can set the camera to rapidly move between positions using IP, RS-232, or RS-485 with separately available controllers, or by using IR control with the included remote. It also features a tally light, and it is photo booth capable. The video output is compressed using H.265, H.264, or MJPEG formats, and you can transmit up to two simultaneous streams using SRT, RTSP, and RTMP protocols.
The camera supports external audio input via a 3.5mm stereo line-level jack for embedding audio into your stream, and a 3.5mm audio output. Power is provided by the included AC adapter or via PoE+ (Power-over-Ethernet) on a supported.

Key Features
UHD 4K (3840 x 2160p) video resolutions up to 60 fps
Built-in auto-tracking capabilities
20x optical zoom lens with a 60.7° horizontal field of view
High performance in low-light scenarios with Wide Dynamic Range
3D noise reduction with the latest low-noise CMOS sensor
Serial (RS-232 / RS-485) and IP control (LAN/WAN)
H.264, H.265, and MJPEG video compression when IP streaming
USB 2.0, HDMI 2.0 / 3G-SDI, NDI|HX 3 / IP streaming (SRT, RTSP, RTMP)
PoE+ (Power over Ethernet) or 12 VDC power supply
Built-in tally light
Photo booth capable

Features
1/1.8" CMOS 8.42MP 4K Sensor
Capture Video Resolutions up to UHD 4K60
20x Optical Zoom, 16x Digital Zoom
HDMI, 3G-SDI, USB, NDI|HX 3 & IP Output
255 Presets, 3.5mm Stereo Audio In/Out
60.7° Angle of View
High Performance in Low Light
RS-232, RS-485 & IP Control Support
Supports H.265/H.264/MJPEG Compression
DC & PoE+ Support, Tally Light

In the box
PTZOptics Move 4K SDI/HDMI/USB/IP PTZ Camera with 20x Optical Zoom (White)
IR Remote Control
12 VDC Power Adapter
USB-A to USB-A Cable
RS-232 Cable
2 x AA Battery

Specifications
Image Sensor 1/2.5”-Type CMOS
Sensor Resolution Effective: 8.42 Megapixel (3840 x 2160)
Shutter Speed 1/10000 to 1/30 Seconds
Optical Zoom Ratio 20x
Max Digital Zoom 16x

External Recording Modes
HDMI / RJ45 / USB
UHD 4K (3840 x 2160) at 25/29.97/50/59.94/60.00 fps
HD (1920 x 1080p) at 25/29.97/50/59.94/60.00 fps
HD (1920 x 1080i) at 50/59.94/60.00 fps
HD (1280 x 720) at 59.94/60.00 fps
SDI/BNC
HD (1920 x 1080p) at 25/29.97/50/59.94/60.00 fps
HD (1920 x 1080i) at 50/59.94/60.00 fps
HD (1280 x 720) at 59.94/60.00 fps

Broadcast Output NTSC/PAL

IP Streaming
H.264, H.265, HTTP, MJPEG, ONVIF, RTMP, RTMPS, RTSP, SRT, TCP, UDP
640 x 360 to 3840 x 2160 to
320 x 240 to 720 x 480 to

Supported Control Protocols
IP
IR
Pelco-D
Pelco-P
RS-232
RS-485
VISCA

PoE Support PoE 802.3af
Material of Construction Aluminum, Plastic

OS Compatibility
Windows 7 to 11
macOS
Linux
Mobile: Android Only

Security Lock Support Kensington Lock Slot
Dimensions (W x H x D) 168.4 x 164.5 x 141.5 mm
Weight 1.47 kg (Body Only)
