Blackmagic Design Media Dock for URSA Cine

Blackmagic Media Dock accelerates your post production workflow by enabling high speed network sharing and upload from up to 3 Blackmagic Media Modules from Blackmagic URSA Cine cameras. 4 x 10G Ethernet ports allow 4 separate edit stations to be connected and edited (?) directly. Blackmagic Media dock also has Ethernet over USB-C, dual AC power inputs for redundancy and an HDMI output for live monitoring of media in real time on a TV or monitor.

Connections

• Interface
• 3 x removable and hot-swappable Blackmagic Media Modules.
• 10G Ethernet Ports
• 4 x 10G BASE-T
• USB-C Port
• 1 x USB 3.0 (up to 5Gb/s). Supports Ethernet Over USB
• HDMI Monitor Outputs
• 1
• Computer Interface
• USB-C or Ethernet for shared file access, configuration and software updates.
• Blackmagic Media Dock
• File Sharing Protocol

Protocol

• SMB
• Computer Connections
• 50 max.
• Cloud Synchronization

Compatible Services

• Dropbox
• Google Drive
• Storage

Storage Type

• Up to 3 Blackmagic Media Modules.
• External Storage Format
• Blackmagic (formatted in camera)
• Displays

HDMI Monitor Out Standards

• 1080p50, 1080p59.94, 1080p60
• Monitor Out Displays
• Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graph.
• Status Indicator
• LED bezel indicator lights around media module bays.
• Device Control

External Control

• USB-C or Ethernet for configuration and software updates.
• Software

Software Included

• Blackmagic Cloud Setup Utility
• Blackmagic Proxy Generator Lite
• Internal software upgrade via Blackmagic Cloud Setup using USB-C port

Product includes

• Blackmagic Media Dock
• Welcome wallet with QR code for software download
