Sony PXW-X400KF 16x Auto Focus Zoom Lens Camcorder Kit

Product code
PXW-X400KF//U
EAN
5013493400542
Condition
New
Special Order Item - Call for exact lead time
Read our reviews
€22,805.46
( €18,693.00 + IVA )

Sensori Full HD a elevata sensibilità
PMW-400 offre immagini Full HD di alta qualità grazie ai tre sensori CMOS Exmor da 2/3" che garantiscono un miglior livello di risoluzione, range dinamico e riproduzione del colore. Il camcorder offre una sensibilità di F12 a 59,94 Hz e F13 a 50 Hz.

Talk to an expert
Whatsapp Live Chat


The PXWX400 offers stunning imaging performance up to 1080/60p, optimized weight balance and ergonomics, and new networking features that enable field-to-air flexibility like never before. The PMWX400 has the perfect balance of performance and practicality. The enhanced ergonomics and mechanical balance allow for all-day shoulder-mount shooting. This camera puts advanced streaming, sophisticated codecs, the power of 1080/60p imagery, the nuances of 10-bit grayscale and the beauty of 4:2:2 color – all within your reach. The PXWX400 supports a variety of Sony viewfinders including the QHD LCD CBKVF02 and the Full HD OLED HDVFEL30 and HDVFEL20. The camcorder offers improved network connectivity, with built-in wireless module, embedded RJ45 Ethernet 100B-T connector and Near Field Communication (NFC)* function for easy Wi-Fi setup and operation via a mobile or tablet with Sony’s Content Browser Mobile™ application. With a 1.5G HD-SDI input for pool feed recording, the PXWX400 is a powerful addition to the Sony XDCAM Camcorder family.



High quality XAVC Long GOP recordings at 50p and 59.94p operations
The PXW-X400 supports a variety of codecs from SD to HD, including MPEG HD 422 50 Mbps in MXF (Material eXchange Format), which is widely accepted by major broadcasters worldwide, and XAVC Intra frame and XAVC Long GOP codecs. XAVC technology is based on the MPEG-4 AVC/H.264 standard, which provides an exceptional performance compression technology. XAVC provides higher picture quality and bit-depth, thus offers extended grading possibilities.

High sensitivity image making
The camcorder’s three 2/3-inch type Exmor CMOS sensors provide superb image quality with sensitivity of F12/F13 and a signal to noise ratio of 62dB. The camcorder’s digital extender offers x2, x3 or x4 operation.

Improved ergonomic design for best-in-class weight-balance
The camcorder has been redesigned to improve the weight and handling capabilities compared to predecessor models. The lighter lens grip resolves any front-heavy issues and dramatically reduces the load on the right-arm. This makes it easier to shoot for long periods and offers more stable images.

Supports Full HD OLED viewfinders*
The camcorder supports Sony viewfinders including the Full HD OLED HDVF-EL30 and HDVF-EL20, as well as the QHD LCD CBK-VF02.
* HDVF-EL30 and HDVF-EL20 are optionally available from December 2015.

Embedded RJ-45 connector
An embedded RJ-45 Ethernet 100B-T connector on the right side of the camcorder provides a robust and fast network connection that can be utilised for file transfer, live streaming and camera control from a web browser.

Near Field Communication* (NFC) function
A Near Field Communication (NFC) function allows easy, one-touch wireless LAN connection to a smartphone or tablet device without manual setting of the network parameters.
* NFC allows close-range wireless communication between the PXW-X400 and an NFC-equipped smartphone or tablet device. This function will be available in June2016.

Built-in wireless module with Content Browser Mobile™
The camcorder’s built-in wireless module gives you more mobility with no cable needed, enabling proxy recording and file transfer or live streaming. In file transfer mode, high-resolution files and XAVC Proxy files can be transferred over wireless connection to cloud or FTP server thanks to Content Browser Mobile* (CBM) application. In “Push” mode, the CBM application enables users to monitor the currently shot video and to wirelessly control camcorder settings such as focus, zoom, iris, white balance, REC START/STOP, and more. With Content Browser Mobile V2.0 proxy trim, proxy partial clip upload, and logging are available. “In streaming” mode, high quality live streaming is provided by the advanced Sony QoS technology embedded in the camcorder and in the PWS-100RX1 network RX station .Non QoS live streaming is also possible with a third-party receiver or VLC player.
*The CBM application can be downloaded from the Google Play Store or App Store.

Dedicated ONLINE button for easy network connection
A dedicated button gives simple on-off control of Network Client Mode, Auto Upload (Proxy) and Live Streaming.

Pool feed (SDI input)
An SD or HD-SDI (up to 1.5G) signal can be recorded by the camcorder, a useful function to record an external feed from another camera.

Lower power consumption
By optimising the design of the hardware, the lightweight PXW-X400 has a low power consumption of 22W (when the wireless function if off, without lens and viewfinder). This enables continuous recording operation for approximately 240 minutes with Sony’s BP-GL95A optional standard-type battery.

Simultaneous Recording on two SxS cards
The PXW-X400 offers a simultaneous recording function for peace-of-mind production. Recording is available on two SxS cards simultaneously as a backup measure within the same codec and operating point* when using the following recording formats; XAVC-Intra, XAVC-Long, MPEG HD422, or MPEG HD420.
* Simultaneous recording with proxy file is supported in all combinations with the above formats an SD card.

Flexible camera system operation
The CA-FB70 Optical Fiber Camera Adaptor or the CA-TX70 Digital Triax Camera Adaptor can be attached to the PXW-X400 for live camera operation. The CA-FB70 enables the PXW-X400 to transmit signals via an optical fibre cable up to 250 m between the CA-FB70 and HXCU-FB70 Optical Fibre Camera Control Unit (CCU) with power and signal transmission. The CA-TX70 transmits signals via triax cable up to 600 m* between the CA-TX70 and HXCU-TX70 Digital Triax Camera Control Unit.



Specs

Camera Specifications:
Built-in Optical Filters1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND
Effective Picture Elements1920 (H) x 1080 (V)
Gain-3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42 dB
Horizontal Resolution1,000 TV lines or higher (1920 x 1080i mode)
Imaging Device3-chip 2/3-type "Exmor" Full HD CMOS
Minimum Illumination0.013 lx (F1.4, +42 dB, 16-frame accumulation)
Optical SystemF1.4 prism system
S/N Ratio62 dB (Y) (Noise Suppression On)
Sensitivity (2000 lx, 89.9% reflectance)F12 (typical) (1920 x 1080/59.94i mode)
F13 (typical) (1920 x 1080/50i mode)
Shutter Speed (Time)59.94i/p, 50i/p: 1/60 sec. to 1/2000 sec.
+ ECS *3 29.97p: 1/40 sec. to 1/2000 sec. + ECS *3 25p: 1/33 sec. to 1/2000 sec.
+ ECS *3 23.94p: 1/32 sec. to 1/2000 sec. + ECS *3
Slow & Quick Motion Function720p: Frame rate selectable from 1 fps to 60 fps
1080p: Frame rate selectable from 1 fps to 60 fps
Slow Shutter2, 3, 4, 5, 6, 7, 8, 16-frame accumulation
White BalancePreset (3200K), Memory A, Memory B/ATW
General Specifications:
Battery Operating TimeApprox. 200 min with BPL80S,
Approx. 240 min with BPGL95A
Dimensions (W x H x D)6 x 10 5/8 x 13 1/8 inches (excluding protrusions,
body only)
MassApprox. 7 lb 15 oz (body only without lens, VF, Mic)
Operating Temperature32 F to 104 F
Power ConsumptionApprox. 22 W (while XAVC recording, colour LCD on)
Approx. 24 W (while XAVC recording, CBKVF02 viewfinder and colour LCD on)
Power RequirementsDC 12 V (11 V to 17.0 V)
Recording FormatVideo: XAVC Intra: - XAVC-I mode: MPEG-4 AVC/H.264,
CBG, Max.112 Mbps XAVC Long: - XAVC-L 50 Mode: MPEG-4 AVC/H.264,
VBR, Max. 50 Mbps - XAVC-L 35 Mode: MPEG-4 AVC/H.264, VBR,
Max. 35 Mbps - XAVC-L 25 Mode: MPEG-4 AVC/H.264, VBR,
Max. 25 Mbps MPEG HD422: -HD422 mode: MPEG-2 422P@HL, CBR,
Max.50 Mbps MPEG HD: - HQ mode: MPEG-2 MP@HL, VBR,
Max.35 Mbps MPEG IMX: *2 - MPEG-2 422@ML, CBR, 50 Mbps DVCAM: - CBR, 25 Mbps
Audio: XAVC Intra: LPCM 24 bits, 48 kHz, 4 channels XAVC Long: LPCM 24 bits,
48 kHz, 4 channels MPEG HD422: LPCM 24 bits, 48 kHz, 4 channels MPEG HD: LPCM 16 bits,
48 kHz, 4 channels MPEG IMX: LPCM 16/24 bits, 48 kHz, 4 channels
*2 DVCAM: LPCM 16 bits, 48 kHz, 4 channels
Proxy Video: XAVC Proxy: AVC/H.264 Main Profile 4:2:0 Long GOP, VBR 1280 720,
9 Mbps 1280 720, 6 Mbps 640 360, 3 Mbps 480 270, 1 Mbps, 500 kbps
Proxy Audio: XAVC Proxy: AAC-LC, 128 kbps, 2 channels
Recording Frame RateXAVC Intra (XAVC-I mode): - 1920 1080: 59.94i, 50i,
29.97p, 25p, 23.98p - 1280 720: 59.94p, 50p
XAVC Long (XAVC-L 50 mode): - 1920 1080: 59.94p, 50p, 59.94i,
50i, 29.97p, 25p, 23.98p - 1280 720: 59.94p, 50p
XAVC Long (XAVC-L 35 mode): - 1920 1080: 59.94p, 50p, 59.94i,
50i, 29.97p, 25p, 23.98p
XAVC Long (XAVC-L 25 mode): - 1920 1080: 59.94i, 50i
MPEG HD422: - 1920 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
1280 720: 59.94p, 50p, 29.97p, 25p, 23.98p
MPEG HD420: - 1920 1080: 59.94i, 50i, 29.97p, 25p, 23.98p - 1440 1080:
59.94i, 50i - 1280 720: 59.94p, 50p
MPEG IMX: - 720 486: 59.94i - 720 576: 50i
DVCAM: - 720 480: 59.94i - 720 576: 50i
Recording/Playback TimeXAVC-I mode: Approx. 120 min. with 128 GB
SxS card Approx. 60 min. with 64 GB SxS card Approx. 30 min. with 32 GB SxS card
XAVC-L 50 mode: Approx. 240 min. with 128 GB SxS card Approx. 120 min.
with 64 GB SxS card Approx. 60 min. with 32 GB SxS card
XAVC-L 35 mode: Approx. 340 min. with 128 GB SxS card Approx. 170 min.
with 64 GB SxS card Approx. 85 min. with 32 GB SxS card
XAVC-L 25 mode: Approx. 440 min. with 128 GB SxS card Approx. 220 min.
with 64 GB SxS card Approx. 110 min. with 32 GB SxS card
MPEG HD422 mode: Approx. 240 min. with 128 GB SxS card Approx. 120 min.
with 64 GB SxS card Approx. 60 min. with 32 GB SxS card
MPEG HD420 HQ mode: Approx. 360 min. with 128 GB SxS card Approx. 180 min.
with 64 GB SxS card Approx. 90 min. with 32 GB SxS card
Approx. 240 min. with 128 GB SxS card Approx. 120 min. with 64 GB SxS card
Approx. 60 min. with 32 GB SxS card
Approx. 440 min. with 128 GB SxS card Approx. 220 min. with 64 GB SxS card
Approx. 110 min. with 32 GB SxS card
Storage Temperature-4F to +140F
Inputs/Outputs Specifications:
Audio InputCH1/CH2: XLR-type 3-pin (female) (x2), Line/Mic/Mic/+48V
selectable LINE: +4, 0, -3 dBu AES/EBU: AES3 compliant MIC: -70 dBu to -30 dBu
Audio OutputXLR-type 5-pin, male, +4/0/-3 dBu (balanced)
DC InputXLR-type 4-pin, male, 11 V to 17 V DC
DC OutputRound type 4-pin, 11 V to 17 V DC, 1.8 A maximum rated current
Genlock InputBNC (x1), 1.0 Vp-p, 75 , unbalanced
HDMI OutputA type, 19-pin (x1)
MICXLR-type 5-pin, female: -70 dBu to -30 dBu
Remote8-pin
SDI InputBNC
SMPTE ST292/ST259 standard compliant
4-channel audio
1.5G
Poolfeed Recording (upto 1080 59.94i)
SDI OutputOutput 1/2: BNC (x2), 0.8 Vp-p,
unbalanced, 3G HD/1.5G HD/SD selectable,
SMPTE ST424/ST425 Level-A/B, ST292/ST259 standard compliant,
4-channel audio
Speaker OutputMonaural, 300 mW output
Timecode InputBNC (x1), 0.5 V to 18 Vp-p, 10 k
Timecode OutputBNC, 1.0 Vp-p, 75
USBUSB 3.0/2.0 4-pin (type A), USB2.0 4-pin (type B), USB2.0 4-pin (type-A)
Video OutputBNC, SD analog composite/HD-Y selectable
Lens Specifications:
Lens MountSony 2/3-inch type bayonet mount
Monitoring Specifications:
Built-in LCD MonitorColour LCD, Screen size: 8.8 cm (3.5 inch) diagonal*18 ,
Aspect ratio: 16:9, Number of pixels: 960 (H) 540 (V) for Video display,
Audio level, TC, battery and media remaining capacity
Compatible Accessories:- DWTB01N/14Digital Body-pack Transmitter
- DWTP01/E3040Digital Plug-on Transmitter
- HDVFEL20OLED 0.7-inch color HD viewfinder
- DWTB01N/30Digital Body-pack Transmitter
- HDVFL7507-inches LCD HD View Finder
- CAFB70Optical fiber camera adaptor for HXC-D70 and PMW320/400/500
- DWA01DDigital Wireless Adaptor
- RCP1500Remote Control Panel (Standard)
- RCP1501Remote Control Panel (Standard)
- HDVFL7707-inches LCD HD View Finder
- RCP1000Remote Control Panel (Simple)
- CBKVF023.5" Color LCD HD Viewfinder for PXW-X500
- HDVFEL30OLED 0.7-inch color Full HD viewfinder with 3.5-inch sub-LCD
- ACDN10AC Adaptor/Charger
- RMB170Handheld remote control unit
- DWRS02D/42Dual Channel Digital Wireless Receiver
- HDVF20A2-inch Type HD B/W CRT Viewfinder
- URXS03D/14UWP-D two-channel slot-in wireless receiver
- DWTB01N/42Digital Body-pack Transmitter
- RCP1001Remote Control Panel "Simple"
- DWRS02D/14Dual Channel Digital Wireless Receiver
- DWRS02D/30Dual Channel Digital Wireless Receiver
- VCT14Tripod Adaptor
- URXS03D/42UWP-D two-channel slot-in wireless receiver
- PWS100RX1Network Station for XDCAM - Wireless Streaming Receiver
- HDVFEL757" OLED HD Electronic Viewfinder
- CBKSP01Optional Soft Shoulder Pad
- BCL5004CH Lithium-Ion Battery Charger
- DWTP01/E4250Digital Plug-on Transmitter
- IFUWLM3Wireless USB module for VPL-E200 series
- URXS03D/30UWP-D two-channel slot-in wireless receiver
- VCTU14Tripod adaptor for professional cameras and camcorders
- CBKWA025GHz/2.4GHz Dual band Wireless LAN Adapter
- EC05X3F5MShotgun Mic Cable (3-Pin XLR to 5-Pin XLR). Formally known as K-1502
- BCL160Lithium-Ion Four Position Battery Charger
- BPGL95AGraphite Lithium-Ion 95Wh Battery
- BPGL65AGraphite Lithium-Ion 65wh Battery
- DWTP01/E1424Digital Plug-on Transmitter
- ECM678/9XShotgun Microphone
- RCP1530Remote Control Panel (Slim)
- MEADSD02SDHC/SDXC Media Adapter
- ECM674/9XShotgun Microphone
- ECM680SStereo Shotgun Microphone
- HDVF2002 HD Viewfinder for all Sony 2/3 HD Cameras/Camcorders



Application
Broadcast
Video Resolution
HD
Sensor Size
2/3"
Media Format
SxS Card
Digital Interface
3G-SDI
Codec
MPEG-2
PXW-X400KF//U
New
5013493400542

Sony Broadcast
