Promise SANLink3 N1 Thunderbolt3 Ethernet Bridge 10Gb/s Adapter

SANLink3 N1 Thunderbolt3 to Nbase-T Adapter

SANLink3 N1 is a compact, bus-powered NBase-T adapter that leverages Thunderbolt™ 3 to connect to Ethernet infrastructures at 1, 2.5, 5, or 10 Gb/s.

Get more from existing networks or take advantage of new infrastructures
SANLink3 N1 NBase-T lets you connect at 1, 2.5 or 5 Gbps over most existing Ethernet wiring or up to 10 Gbps on the latest high-speed networks.

Convenient and portable connectivity solution
SANLink3 N1 is bus-powered and requires no separate power supply. With its compact size and included Thunderbolt™ 3 cable, you can now stay mobile without sacrificing connection speeds.

Do more with a single Thunderbolt™ 3 port
Daisy-chain multiple Thunderbolt™ 3 devices – High resolution displays, Pegasus3 RAID storage and connect to 10G Ethernet with a SANLink3 N1 and still get maximum performance!

The most affordable high speed Ethernet connection solution
SANlink3 N1 raises the bar for high-speed Ethernet connectivity and affordability. No other Thunderbolt™ 3 adapter provides these capabilities in such small compact package.

Specifications
• Ethernet Port: NBASE-T Ethernet Port
• Thunderbolt Technology Ports: Single Thunderbolt™ 3 technology port (40 Gbps)
• Transfer Rates: 1250 MB/s at 10 Gb, 625 MB/s at 5 Gb, 312.5 MB/s at 2.5 Gb, 125 MB/s at 1 Gb
• Host Bus Type: Single 40 Gbps Tunderbolt™ 3 port
• Protocols: IEEE 802.3an - 10GBASE-T, IEEE 802.3bz - 2.5G/5GBASE-T, IEEE 802.3ab - 1000BASE-T, IEEE 802.3u - 100BASE-TX
• Dimensions: 24 mm (H) x 96.4 mm (W) x 48 mm (D)
• Weight: 120 g/ 0.26 lb
• Warranty: 3 year limited warranty
• Requirements: Workstation or portable with Thunderbolt™ 3 Port (Thunderbolt™ 3 cable included)
• OS Support: OS X 10.13.3 or later, Windows 10 (64-bit-available driver download)
